| Product parameters | ||||
| Import and export diameter | reference flow | Cylinder specification | Number of magnets | Magnetic strength |
| DN20 | 0.6-1.6m³/h | φ159 | 5 _ | 12000GS/13500GS |
| DN25 | 1.1-2.8m³/h | φ159 | 5 _ | 12000GS/13500GS |
| DN40 | 2.5-6m³/h | φ159 | 5 _ | 12000GS/13500GS |
| DN50 | 4-9.5m³/h | φ159 | 5 _ | 12000GS/13500GS |
| DN65 | 7.3-17.5m³/h | φ159 | 7 _ | 12000GS/13500GS |
| DN80 | 10-24m³/h | φ200 | 7 _ | 12000GS/13500GS |
| DN100 | 14.7-35.2m³/h | φ200 | 7 _ | 12000GS/13500GS |
| DN125 | 22.7-52.7m³/h | φ250 | 9 _ | 12000GS/13500GS |
| DN150 | 33-79.3m³/h | φ250 | 9 _ | 12000GS/13500GS |
| DN200 | 64-154m³/h | φ300 | 9 _ | 12000GS/13500GS |
| Technical Parameters: 1. Reasonable structural design ensures the best iron removal effect and does not hinder the flow of materials; 2. The standard working temperature is ≤80°C, and the maximum working temperature can reach 350°C under special requirements; 3. Pressure use requirements or other special requirements can be designed according to customer requirements. |
||||
